Drawing in 2D

Everything 2D is drawn on the preview's canvas through ctx, its 2D drawing surface. This page lists what it can do, grouped by job, with a short program for each group that you can paste into a Python file and run.

The basics

  • Positions are in points, measured from the top-left corner. x grows to the right and y grows down. The bottom-right corner is (width, height).
  • Drawing is sharp on every screen: the preview takes care of high-resolution displays for you.
  • Angles are in radians. A full turn is math.tau (about 6.283), half a turn is math.pi. math.radians(90) turns degrees into radians.
  • Colours are text: a name ("red", "skyblue"), a hex code ("#ff8800"), "rgb(255, 136, 0)", "rgba(255, 136, 0, 0.5)" (the last number is opacity, 0 to 1), or "hsl(30, 100%, 50%)" (hue in degrees, then saturation and lightness).
  • Two spellings, one call. Every name works in snake_case or in its standard form: ctx.fill_rect(...) is ctx.fillRect(...), and ctx.fill_style is ctx.fillStyle. This guide uses snake_case from here on.
  • The preview's background is white in the light theme and near-black in the dark theme. Paint your own background first so your drawing looks the same in both.

Rectangles

CallWhat it does
ctx.fill_rect(x, y, w, h)A filled rectangle, top-left corner at x, y
ctx.stroke_rect(x, y, w, h)The outline of a rectangle
ctx.clear_rect(x, y, w, h)Erases that area back to the preview's background
def draw():
    ctx.fill_style = "white"
    ctx.fill_rect(0, 0, width, height)

    ctx.fill_style = "steelblue"
    ctx.fill_rect(40, 40, 160, 100)

    ctx.stroke_style = "crimson"
    ctx.line_width = 6
    ctx.stroke_rect(240, 40, 160, 100)

Paths: lines, circles and any shape

A path is a shape you build from pieces, then fill or outline. Start with begin_path(), add pieces, then call fill() or stroke() (or both).

CallWhat it adds
ctx.begin_path()Starts a new, empty shape
ctx.move_to(x, y)Lifts the pen and puts it down at x, y
ctx.line_to(x, y)A straight line to x, y
ctx.arc(x, y, r, start, end)Part of a circle around x, y. 0 to math.tau is a whole circle. Add True at the end to go anticlockwise.
ctx.ellipse(x, y, rx, ry, rotation, start, end)Part of an oval
ctx.rect(x, y, w, h)A rectangle, as part of the path
ctx.round_rect(x, y, w, h, r)A rectangle with rounded corners of radius r
ctx.quadratic_curve_to(cx, cy, x, y)A curve to x, y, pulled towards one control point
ctx.bezier_curve_to(c1x, c1y, c2x, c2y, x, y)A curve with two control points
ctx.close_path()A straight line back to the start of the shape
ctx.fill()Fills the shape with fill_style
ctx.stroke()Draws its outline with stroke_style and line_width
import math

def draw():
    ctx.fill_style = "#f4f1ea"
    ctx.fill_rect(0, 0, width, height)

    # a circle
    ctx.fill_style = "orange"
    ctx.begin_path()
    ctx.arc(100, 100, 50, 0, math.tau)
    ctx.fill()

    # a triangle, filled and outlined
    ctx.begin_path()
    ctx.move_to(200, 150)
    ctx.line_to(260, 50)
    ctx.line_to(320, 150)
    ctx.close_path()
    ctx.fill_style = "mediumseagreen"
    ctx.fill()
    ctx.stroke_style = "darkgreen"
    ctx.line_width = 4
    ctx.stroke()

    # a wave
    ctx.begin_path()
    ctx.move_to(20, 220)
    ctx.bezier_curve_to(120, 140, 220, 300, 340, 220)
    ctx.stroke_style = "royalblue"
    ctx.stroke()

    # a rounded button
    ctx.begin_path()
    ctx.round_rect(360, 60, 140, 60, 16)
    ctx.fill_style = "teal"
    ctx.fill()

Colours, gradients, lines and transparency

Every way to write a colour, including hsl explained step by step, is on the Colours page.

SettingWhat it does
ctx.fill_style = "red"The colour (or gradient) for fills and fill_text
ctx.stroke_style = "blue"The colour (or gradient) for outlines
ctx.line_width = 4Outline thickness, in points
ctx.line_cap = "round"How line ends look: "butt", "round" or "square"
ctx.line_join = "round"How corners look: "miter", "round" or "bevel"
ctx.set_line_dash([10, 5])Dashed lines: 10 drawn, 5 gap. [] is solid again.
ctx.global_alpha = 0.5Makes everything after it see-through: 0 invisible, 1 solid
ctx.shadow_color, ctx.shadow_blur, ctx.shadow_offset_x, ctx.shadow_offset_yA soft shadow behind what you draw
ctx.global_composite_operation = "lighter"How new drawing mixes with what is there ("source-over" is normal)

A gradient is made once, given colour stops from 0 to 1, then used as a style:

CallMakes
ctx.create_linear_gradient(x0, y0, x1, y1)A gradient along a line
ctx.create_radial_gradient(x0, y0, r0, x1, y1, r1)A gradient between two circles
gradient.add_color_stop(position, colour)A colour at a point along it
import math

sky = ctx.create_linear_gradient(0, 0, 0, 400)
sky.add_color_stop(0, "#1e3c72")
sky.add_color_stop(1, "#f7b267")

glow = ctx.create_radial_gradient(300, 120, 5, 300, 120, 60)
glow.add_color_stop(0, "white")
glow.add_color_stop(1, "rgba(255, 220, 120, 0)")

def draw():
    ctx.fill_style = sky
    ctx.fill_rect(0, 0, width, height)

    ctx.fill_style = glow
    ctx.fill_rect(220, 40, 160, 160)

    # see-through circles
    ctx.global_alpha = 0.6
    for i, colour in enumerate(["red", "lime", "blue"]):
        ctx.fill_style = colour
        ctx.begin_path()
        ctx.arc(100 + i * 40, 260, 50, 0, math.tau)
        ctx.fill()
    ctx.global_alpha = 1

    # a dashed, round-ended line
    ctx.stroke_style = "white"
    ctx.line_width = 6
    ctx.line_cap = "round"
    ctx.set_line_dash([12, 14])
    ctx.begin_path()
    ctx.move_to(20, 360)
    ctx.line_to(width - 20, 360)
    ctx.stroke()
    ctx.set_line_dash([])

Text and fonts: drawing text on the canvas

Call or settingWhat it does
ctx.font = "bold 24px sans-serif"Style, size and family, written the way web pages write fonts. Families that always work: sans-serif, serif, monospace, system-ui.
ctx.fill_text(text, x, y)Draws filled text
ctx.stroke_text(text, x, y)Draws the outline of the text
ctx.text_align = "center"Where x is: "left", "center" or "right"
ctx.text_baseline = "middle"Where y is: "alphabetic" (the default, the line letters sit on), "top", "middle" or "bottom"
await ctx.measure_text(text).widthHow wide the text will be, in points (a read: see Reading a value back)

Emoji are text too, so ctx.fill_text("🚀", x, y) draws a rocket.

def draw():
    ctx.fill_style = "#202833"
    ctx.fill_rect(0, 0, width, height)

    ctx.fill_style = "white"
    ctx.font = "bold 40px sans-serif"
    ctx.text_align = "center"
    ctx.text_baseline = "middle"
    ctx.fill_text("Centred title", width / 2, 60)

    ctx.font = "20px monospace"
    ctx.text_align = "left"
    ctx.fill_style = "#9fe"
    for i, line in enumerate(["first line", "second line", "third line"]):
        ctx.fill_text(line, 30, 130 + i * 30)

    ctx.font = "64px sans-serif"
    ctx.fill_text("🌈 ⭐ 🚀", 30, 260)

    ctx.font = "bold 48px serif"
    ctx.stroke_style = "gold"
    ctx.line_width = 2
    ctx.stroke_text("Outline", 30, 340)

Moving, turning and scaling: transforms

A transform moves the whole drawing grid, so the shapes after it are drawn in the moved grid. It is the easy way to rotate something around its own centre.

CallWhat it does
ctx.translate(x, y)Moves the starting corner (0, 0) to x, y
ctx.rotate(angle)Turns the grid around (0, 0), by angle radians clockwise
ctx.scale(sx, sy)Stretches the grid. ctx.scale(2, 2) draws everything twice as big.
ctx.save()Remembers the current transform and every style setting
ctx.restore()Goes back to what save() remembered

Always pair save() with restore(), so one shape's transform does not leak into the next.

import math

angle = 0

def update(dt):
    global angle
    angle += dt

def draw():
    ctx.fill_style = "white"
    ctx.fill_rect(0, 0, width, height)
    for i in range(5):
        ctx.save()
        ctx.translate(80 + i * 110, height / 2)   # move to the square's centre
        ctx.rotate(angle * (i + 1) / 2)          # spin around it
        ctx.scale(1 + i * 0.2, 1 + i * 0.2)
        ctx.fill_style = f"hsl({i * 60}, 70%, 50%)"
        ctx.fill_rect(-20, -20, 40, 40)          # drawn around (0, 0)
        ctx.restore()

Pictures

load_image(address) loads a picture from a web address or a data: address and gives you an image to draw. It draws once it has finished loading, so draw it in draw() and it appears as soon as it is ready.

CallWhat it does
img = load_image("https://…/picture.png")Starts loading a picture
ctx.draw_image(img, x, y)Draws it at its own size, top-left at x, y
ctx.draw_image(img, x, y, w, h)Draws it stretched to w by h
ctx.draw_image(img, sx, sy, sw, sh, x, y, w, h)Draws one part of it (for sprite sheets)
ctx.image_smoothing_enabled = FalseKeeps pixel art crisp when you scale it up

This picture is made in Python as a small SVG drawing, so it needs no internet:

from urllib.parse import quote

svg = """<svg xmlns='http://www.w3.org/2000/svg' width='64' height='64'>
<circle cx='32' cy='32' r='30' fill='gold'/>
<circle cx='22' cy='26' r='5' fill='black'/>
<circle cx='42' cy='26' r='5' fill='black'/>
<path d='M18 40 Q32 54 46 40' stroke='black' stroke-width='4' fill='none'/>
</svg>"""

def draw():
    ctx.fill_style = "#cde"
    ctx.fill_rect(0, 0, width, height)
    ctx.draw_image(smiley, 20, 20)
    ctx.draw_image(smiley, 120, 20, 160, 160)

Sprites

A Sprite is a picture that moves. The picture can be an emoji or any short text, or an image from load_image. It draws itself centred on its x, y.

rocket = Sprite("🚀", x=100, y=200, size=64)
PartWhat it is
pictureAn emoji or text, or an image from load_image
x, yWhere its centre is
vx, vyIts speed in points per second, used by update(dt)
angleHow far it is turned, in radians
sizeHow big it is, in points (48 unless you say)
visibleFalse hides it
sprite.update(dt)Moves it by its speed: x += vx * dt, y += vy * dt
sprite.draw()Draws it (call this in your draw())
sprite.touches(other)True when two sprites overlap
import math, random

fish = [Sprite("🐟", random.uniform(0, 400), random.uniform(40, 300), size=40) for _ in range(6)]
for f in fish:
    f.vx = random.uniform(40, 120)
shark = Sprite("🦈", 0, 200, size=72)
shark.vx = 60

def update(dt):
    for f in fish + [shark]:
        f.update(dt)
        if f.x > width + 40:
            f.x = -40
    for f in fish:
        f.visible = not f.touches(shark)
    shark.angle = math.sin(shark.x / 40) * 0.2

def draw():
    ctx.fill_style = "#0b4f6c"
    ctx.fill_rect(0, 0, width, height)
    for f in fish:
        f.draw()
    shark.draw()

The simple game tutorial builds a whole game from sprites.

Everything else

ctx is the standard 2D drawing surface, so any other operation it has works the same way, in either spelling: clipping (ctx.clip()), pixel access (ctx.get_image_data, ctx.put_image_data), filters (ctx.filter = "blur(4px)") and the rest. Reading pixels back is a read, so it needs await and is slow; drawing is not. 2D functions lists every one, grouped, with pictures.
